MikroTik Chateau LTE7 5 Port WiFi 5 Gigabit Router | D53G-5HacD2HnD-TC&R11e-LTE7
S53UG+5HaxD2HaxD-TC&R11e-LTE7
Delivery
Payment options
Our advantages
Manufacturer's warranty .
SMS notification .
Return and exchange .
Different payment methods .
Best price .
Specification
Specifications
- Product code S53UG+5HaxD2HaxD-TC&R11e-LTE7
- ArchitectureARM 64bit
- CPUIPQ-6010
- CPU core count4
- CPU nominal frequencyauto MHz
- CPU Threads count4
- Switch chip modelIPQ-6010
- RouterOS license4
- Operating SystemRouterOS v7
- Size of RAM1 GB
- Storage size128 MB
- Storage typeNAND
- MTBFApproximately 200'000 hours at 25C
- Tested ambient temperature-40°C to 70°C
Powering
- Number of DC inputs1 (DC jack)
- DC jack input Voltage12-28 V
- Max power consumption21.5 W
- Max power consumption without attachments15.5 W
- Cooling typePassive
Mobile
- 3G CategoryR8 (DL: 42.2 Mbps; UL: 5.76 Mbps)
- 3G bands1 (2100 MHz)
5 (850 MHz)
8 (900 MHz)
3 (1800 MHz) - LTE Category7 (DL: 300 Mbps; UL: 100 Mbps)
- MIMO DL2x2
- MIMO UL1x1
- LTE FDD bands1 (2100 MHz)
3 (1800 MHz)
5 (850 MHz)
7 (2600 MHz)
8 (900 MHz)
20 (800 MHz)
28 (700 MHz)
32 (1500 MHz) - LTE TDD bands38 (2600 MHz)
40 (2300 MHz)
41 (2500 MHz) - TAC35312597
Wireless specifications
- Wireless 2.4 GHz Max data rate574 Mbit/s
- Wireless 2.4 GHz Number of chains2
- Wireless 2.4 GHz standards802.11b/g/n/ax
- Antenna gain dBi for 2.4 GHz3
- Wireless 2.4 GHz chip modelQCN-5022
- Wireless 2.4 GHz generationWi-Fi 6
- Wireless 5 GHz Max data rate1200 Mbit/s
- Wireless 5 GHz Number of chains2
- Wireless 5 GHz standards802.11a/n/ac/ax
- Antenna gain dBi for 5 GHz6
- Wireless 5 GHz chip modelQCN-5052
- Wireless 5 GHz generationWi-Fi 6
Ethernet
- 10/100/1000 Ethernet ports4
- Number of 2.5G Ethernet ports1
Peripherals
- Number of SIM slots1 Modem (Micro SIM)
- Number of USB ports1
- USB Power ResetYes
- USB slot typeUSB type A
- Max USB current (A)1
Other
- CPU temperature monitorYes
- PCB temperature monitorYes
- Voltage MonitorYes
- Mode buttonYes
Certification & Approvals
- CertificationCE, EAC, ROHS
- IP20
Included parts
24V 1.2A power adapter
UTP Flat Cable (1.5m)
The manufacture company
MikroTik
